Gas burner

Product introduction: Our gas burner is made of stainless steel (1Cr18Ni9Ti) according to its overall length, width and height, with gas pressure of 1200Pa-1600Pa, suitable for matching the diameter of 1.9m-4.0m kiln.

Type number: L x W x H (mm) 3150x1450x600-4970x2240x1078

Matching kiln type: φ1.9-φ4.0

Application: combustion system of rotary kiln in electric power, chemical industry, metallurgy, building materials and other industries.

Gas burner product introduction

The gas burner is specially developed for the combustion of single or multiple gas fuels in rotary kiln. The burner not only guarantees the advantages and characteristics of the four-channel burner, but also increases the combustion adaptability. The unique structure and reasonable process parameters ensure that the gas fuel and air, the primary air and the secondary air mix fully, so that the thermal strength is greater, the combustion efficiency is higher, the adjustment is more simple, can be applied to a variety of metallurgical, chemical rotary kiln.

Outstanding advantage

1, Hot gas pressure is 300-500Pa, temperature 350-500℃;

2, The valve adopts high temperature valve, ignition, detection adopts high temperature design;

3, Continuous adjustment of gas volume, PID control adjustment, to meet the requirements of automatic control of furnace temperature;

4, The burner has automatic ignition, flame detection, automatic combustion control functions;

Working principle

Gas burner is a heating facility with hot gas as the heat source, which is used to realize the special equipment of hot gas combustion process. It is used in magnesium metal production line to provide heat source for magnesium metal rotary kiln system. The main working principle is to introduce hot gas and combustion-supporting air into the gas burner for combustion according to the maximum proportion and maximum mixing conditions, and meet the requirements of the direction, shape, rigidity and spreading of the flame during the heating process.

Technical parameter
